Aquarian 650R Reflex Gauge

The Aquarian 650R Reflex Gauge is rated for 975psi (67bar) for process applications, and 350psi (24bar) for steam applications. It provides excellent visibility of liquid level. Light refracting grooves in the glass cause the liquid to appear black and steam to appear white. The high contrast between water and vapor allows this style gauge to be stacked on top of one another without concern for blind spots between gauges. Recessed gasket surfaces in both the cover and body facilitate glass and gasket alignment and also help prevent gasket blowout. Belleville spring washers maintain constant gasket loading under thermal and pressure cycles.
